Grid Ball Mill

Ball mills are commonly used in metal and non-metal mineral processing plant, chemical industry, construction materials, electricity industry and other industries, to grinding ore, coal and other m...
没有此类产品
I want to make an inquiry
OVERVIEW
Ball mills are commonly used in metal and non-metal mineral processing plant, chemical industry, construction materials, electricity industry and other industries, to grinding ore, coal and other material with all kinds of hardness. Used for grind size relatively coarse ore, first grinding. We can customize according to your demond.

1. Feeder 2. Feed component 3. Cylinder 4. Discharge component 5. Bearing component 6. Driving section 7. Rack
Specifications of the Grib Ball Mill

Model

The shell

Effective volume m3

  Max. load of ball

Capacity
t/h

E-motor

Dimension of th e outline

Weight
kg

Diameter mm

Length mm

Revolution
r/min

   Model

Power
kw

Length mm

Width mm

Height mm

MQG(Y)0909

900

900

39.2

0.45

0.96

0.22~1.074

Y225S-8

18.5

4027

2213

2015

4400

MQG(Y)0918

900

1800

39.2

0.9

1.92

0.44~2.14

Y225M-8

22

4196

2336

1165

5340

MQG(Y)1212

1200

1200

31.33

1.1

2.4

0.17~4.1

Y250M-8

30

5188

2794

2540

11438

MQG(Y)1224

1200

2400

31.33

2.2

3.96

0.26~6.15

Y315S-8

55

6673

2994

2540

13100

MQG(Y)1515

1500

1500

29.2

2.5

5

1.4~4.5

YR280S-8

55

5790

3236

2766

14295

MQG(Y)1530

1500

3000

29.64

5

8.6

2.8~9

JR125-8

95

7037

3246

2766

17836.4

MQG(Y)2122

2100

2200

23.6

6.5

16

5~29

JR128-8

155

7750

4839

3794

41540

MQG(Y)2130

2100

3000

23.6

9

20

6.5~36

JR137-8

210

8970

4839

3795

50600

MQG(Y)2430

2400

3000

20.59

11.4

22.5

7.2~90

YR4005-8

280

9305

5703

3745

57694

MQG(Y)2736

2700

3600

20.6

18.5

36

25~38

TDMK400-32

400

10165

5826

4674

76830

MQG(Y)2740

2700

4000

21

20.4

40

25~38

TDMK400-32

400

10495

5826

4074

84627

MQG(Y)2745

2700

4500

21

23

45

25~38

TDMK500-32

500

11465

5826

4674

87139

MQG(Y)2844

2800

4400

23.57

21.25

42.7



TDMK500-32

500

11161

5351

4442

85348

MQG(Y)3230

3200

3000

18.1

21.2

46

65~85

TDMK630-36

630

13700

6760

5100

108000

MQG(Y)3231

3200

3100

18.1

21.9

47

70~90

TDMK630-36

630

9665

6626

5148

110900

MQG(Y)3236

3200

3600

18.1

25.4

58

95~110

TDMK630-36

630

11600

7200

5700

139500

MQY3245

3200

4500

18.5

32.8

58

90~110

TDMK800-36

800

13117

7267

5653

142380

MQG3245

3200

4500

18.5

32.8

65

95~110

TDMK800-36

800

13975

7030

5150

145138

MQG3640

3600

4000

17.5

38

80

100~120

TDMK1000-36

1000

13417

7200

5500

152700

MQY3640

3600

4000

17.5

38

80

100~120

TDMK800-36

800

12600

7200

5500

146100

MQG3645

3600

4500

17.3

42

87

100~130

TM1250-40

1250

15200

7700

6300

159131

MQY3645

3600

4500

17.3

42

76

95~120

TM1250-40

1000

15010

7230

6326

152531

MQG3654

3600

5400

17.3

48

100

50~210

TDMK1600-40

1600

15836

7675

5500

179045

MQY3654

3600

5400

17.3

48

90

40~190

TDMK1250-40

1250

15010

7675

5500

172445

MQG3660

3600

6000

17.3

52

109

55~230

TDMK1600-40

1600

16645

7675

5500

184564

MQY3660

3600

6000

17.3

52

109

45~190

TDMK1250-40

1250

15918

7675

5500

177964
